Industrial RS485 Infrared CO2 Sensor for Air Quality Monitor (IP65, NDIR, 400-5000ppm) - แท้ DFRobot

Precision NDIR Technology

The sensor employs advanced NDIR technology, a highly stable and accurate method for CO2 measurement. This enables a measurement range of 400 to 5000 PPM, with high accuracy specifications: ±50 PPM for concentrations between 400-2000 PPM, and ±100 PPM for concentrations above 2000 PPM. The quick 5-second response time and optional manual calibration capability ensure real-time and dependable data acquisition. An intuitive indicator light provides immediate visual feedback on the sensor's operational status.

Robust Industrial Design

Featuring an IP65 protection rating and a threaded fixed installation design, this sensor is built for durability and easy deployment in demanding conditions. The probe is equipped with a waterproof and breathable membrane made from a polymer material, effectively preventing water vapor and dust ingress while maintaining optimal air permeability. This robust construction ensures a longer service life and reliable performance in harsh environments.

Seamless Integration with RS485 Modbus-RTU

Equipped with an RS485 output interface and supporting the standard Modbus-RTU communication protocol, the sensor offers straightforward integration into existing control systems. It can be easily interfaced with modules like the Gravity: RS485 to UART active isolation signal conversion module (DFR0845) for quick prototyping and data reading on platforms such as Arduino UNO R3, simplifying development and deployment. The sensor operates on a DC 12V power supply with a low working current of less than 10mA.

• NDIR technology, measuring range 400~5000PPM
• Threaded fixed installation design, easy installation
• Protection grade IP65, longer service service life
• RS485 interface, standard Modbus-RTU protocol

Applications

• Indoor CO2 concentration monitoring
• Pipeline CO2 concentration monitoring
• Greenhouse plant environment monitoring
• Fresh air system environment testing

• Power supply voltage: DC12V
• Working current: <10mA
• Output mode: RS485
• Measurement range: 400-5000ppm
• Accuracy: 400-2000ppm@±50ppm, >2000ppm@±100ppm
• Response time: 5s
• Stabilization time: 60s
• Working temperature: -30~80°C
• Working humidity: 5~90%RH
• Storage temperature: -30~80°C
• Storage humidity: 5~90%RH
• Casing material: plastic
• Protection level: IP65
• Mounting thread diameter: M18
• Size: 75*16.5mm
• Sensor cable length: 1m

• RS485 Infrared CO2 Sensor(400-5000ppm) x1

Documents

• Product wiki
