TJA1050 CAN Module CAN Bus Module CAN Bus Transceiver STM32 Code

TJA1050 CAN module CAN bus module CAN bus transceiver STM32 code

Feature:
1. WORKING CURRENT: Typical value of CAN bus module is 5mA, standby current is 1 microampere, except power indicator
2. OPERATING TEMPERATURE: Bus module support industrial grade ‑40℃ to 85℃, logical interface support 2.54mm needle, KAN interface supports wiring terminals
3. POWERFUL DRIVE: TJA1050 bus transceiver module possess impedance matching, ensure driving ability, long distance data transmission anti radiation
4. HIGH SPEED FLEXIBLE: Controller development board support standard frame, extended frame and remote frame, communication rate supports high speed 1M b/s
5. VOLTAGE INFORMATION: The voltage span of CAN bus module is 4.75 ~ 5.25v, the logical level voltage is compatible with 3.3v and 5v

Specification:
Item Type: CAN Bus Transceiver Module
Model Number: TJA1050
Voltage Span: 4.75 ~ 5.25v
Logic Level Voltage: Compatible with 3.3v and 5v
Number of Nodes: 110
Communication Rate: High speed 1M b/s
Standby Mode: Green
Module Grote: Approx. 35 x 11mm / 1.38 x 0.43in
Logical Interface: Approx. 2.54mm / 0.1in pin
CAN Interface: Wiring terminal
