1 whole soldering station using a conductive material, designed to prevent static electricity and clean room environments (ESD) has this feature.
2 heating element made of imported temperature materials made with advanced technology, long life.
3 heating element using a low voltage AC source power supply, to ensure that the anti-static, no leakage, no interference.
Set and control 4.200 ~ 480 ℃ temperature stable and accurate.
5 all-copper large transformers, rapid warming.
6. handle special lightweight, long-term use without fatigue.
7 heating element is completely isolated by the main power grid.
8 iron part in aviation connectors and high temperature anti-static silicon rubber cable with temperature control units connected.
9 unique temperature locking device to prevent staff hackneyed temperature.
10. split design, display easy. Specifications Input voltage: 220VAC ± 10% Power consumption: 60W Temperature range: 200 ℃ ~ 480 ℃ setting mode: knob to adjust theuse of 1 Operating Instructions (1) temperature control knob to 200 ℃ position. (2) Connect the iron and console. (3) Connect the power supply. (4) open the switch, the power indicator LED that lights up. (5) the temperature of the temperature control knob to the applicable position. (6) the use of a suitable temperature. Too low temperature will slow the flow of solder, solder temperature is too high flux will burn and turn white thick dry, resulting in Weld or burn circuit boards. When soldering tip temperature in accordance with the needs correctly set point, the point is to have good welding can be sure of. Solder alloy commonly used in the electronics industry is 60% tin, 40% lead (60/40). Suitable for soldering iron tip according to different manufacturers vary Temperature 2 Temperature Lock (1) the temperature setting to the proper temperature. (2) with a screwdriver at a temperature knob clockwise to tighten the locking screw until the temperature setting knob does not move. (3) When the temperature re-set, screwdriver counterclockwise rotation locking screw loose. 3 non-stick tin tip reason (1) tip temperature exceeds 400 ℃. (2) to be used in the soldering tip surface did not give proper plus tin. (3) the lack of flux in welding, soldering, repair, welding and other operations. (4) Wipe the tip on the high sulfur content or dry sponge and a rag. (5) come into contact with organic material such as plastic, silicon (Si) quality grease and other chemicals. (6) the use of impure and low tin content solder. Tip replacement and treatment tip can unscrew the sleeve out replacement. Be sure to turn off the power supply temperature control units and allow the tip to cool down before removing the tip, remove the sleeve fixed premises oxide dust formation. Care must be taken to avoid this dust into the eyes. Replace the tip and the normal hand strength to lock sleeve. When replacing the new iron core, iron core should extend stainless steel pipe 23mm, and then lock the handle iron core mounting screws Note: You must be careful not to lock too tight, otherwise it will damage the heating element. General cleaning (1) iron grip or temperature control units with a cloth moistened with a small amount of housing can be liquid detergent to clean.(2) Do not immersed in fluid temperature control units or allow liquids to flow into the housing. (3) Do not use any solvents to clean the shell. The new tip 1 replacement tip, please use 936 tip. 2 When any time using the new tip, please follow these steps will enable greatly extended tip life. ⑴ The temperature setting control knob to low position. Turn the power "switch." ⑵ heating arrive after 200 ℃, the surface of the tip soldering flux containing tin wire plus. ⑶ continued after heating at 200 ℃ for five minutes, and then go to the proper temperature setting controls the use of temperature location. After ⑷ reach the appropriate temperature, to get started. Note: When any time using the new tip, every day is best able to tip out and clean up the internal foreign body! Proper use of the soldering iron (a) the need to maintain a clean tip. (2) Do not touch the iron when using the heating element. (3) the use of non-violence, the use of iron (for example: a hard object hitting the head with a soldering iron). Maintenance tip soldering iron temperature control in order to allow the operation to ensure a well-functioning properly, please note the following recommendations. (If there are certain iron or temperature control units function of factors is not functioning properly, please contact the nearest service support service at). Tip supplied all alloy head, if used properly, will have a longer life. 1 off before disabling certain wetting surface at the tip add the appropriate amount of tin, just wipe before welding. 2 Do not let the tip long stay in the high temperature, easy to make the tip surface plating layer of cracking. 3 When soldering, do not be too much pressure to the tip of friction joints, this process does not change the thermal performance, but will make the tip damage. 4 Never clean up the tip with a rough material or rasp. 5 If the surface is non-stick tin oxide, can be used as needed 600 to 800 purpose magic emery cloth and carefully rubbing alcohol with a B or an equivalent solution to clean 6 Do not use excessive chlorine or acid flux. Use of a synthetic resin or only the flux of reactive resin. Note: Every 24 hours or at least once a week, to clean up and clear out the tip inner sleeve foreign body. Security Code when the power is turned on, the tip temperature is hot. Given the abuse may cause burns or fires, please observe the following matters: 1 Do not touch the metal parts of the tip nearby. 2 Do not use combustible material in the vicinity of the tip. 3 notify other personnel workshop, tip burn easily, may lead to dangerous accidents, or after the completion of rest should turn off the power. 4. tip replacement parts or devices, turn off the power, and until the tip is cooled to room temperature. To avoid damaging the welding station and safe working environment, shall comply with the following: This product uses three-wire grounding plug, must be inserted into the three-hole grounded outlet. Do not change the plug or use an ungrounded three adapters leaving poorly grounded. 1 For an extension cord, use a grounded three-wire power cord. 2 Do not use the soldering iron tip to work outside. 3 Do not knock the table to remove residual iron, a move that could seriously damage the earthquake iron. 4 Do not tamper welding sets. Never use welding sets 5 sets of wet welding, or when your hands are wet. 6. welding will smoke, workshops should have good ventilation. Without any possible physical injury or damage to objects frivolous use when soldering station 7.
